Model | RT-S95 | RT-S02 | RT-S03 | RT-S06 | RT-S09 | ||||
Type | Stored Pressure Type | ||||||||
Extinguishant | AFFF Foam (Premix) / Water | ||||||||
Capacity | 950mL | 2 L | 3 L | 6 L | 9 L | ||||
Propellant | Nitrogen (N2) | ||||||||
Valve | Controllable Brass Valve with Pressure Indicator | ||||||||
Cylinder diameter | 85mm | 110mm | 130 mm | 165 mm | 165 mm | ||||
Cylinder height | 300 | 398 mm | 416 mm | 506 mm | 621 mm | ||||
Overall Height | 350 | 396 mm | 475 mm | 605 mm | 720 mm | ||||
Approx Full Weight | 1.63 kg | 3.7 kg | 4.9 kg | 9.5 kg | 13.3 kg | ||||
Working Temp. Range | -20°C to + 55°C | ||||||||
Working Pressure | 12 bar (20℃) | ||||||||
Test Pressure | 21 Bar (362 PSI) | ||||||||
Burst Pressure | Exceeds 69 Bar (1000 PSI) | ||||||||
Approx Discharge Range | 2.5 m | 6 m | 6 m | ||||||
Approx Discharge Time | 18 sec | 68 sec | 75 sec | ||||||
Fire Rating | 5A / 34B | 13A / 183B | 13A | ||||||
Fire Class | 0.5A / 13B | 1A / 55B | 1A / 55B | 1A / 55B | 2A / 89B | ||||
Internal Coating | Thermoplastic Powder Coating (PPA) | ||||||||
Mounting | Wire Vehicle Bracket | Metal 'L' Wall Bracket |
