Capacity | 1KG | 2KG | 3KG | 4KG | 6KG | 9KG | 12KG |
Out-Diamter(mm) | 85 | 110 | 130 | 130 | 160 | 180 | 185 |
Cylinder Height(mm) | 280 | 315 | 335 | 415 | 445 | 510 | 560 |
Volume(L) | 1.4 | 2.6 | 3.9 | 5.1 | 7.8 | 11.5 | 13.2 |
Full Weight(kg) | 2.2 | 3.7 | 5.2 | 6.8 | 9.5 | 13.7 | 17.2 |
Temperature Range(℃) | -30℃~60℃ | -30℃~60℃ | -30℃~60℃ | -30℃~60℃ | -30℃~60℃ | -30℃~60℃ | -30℃~60℃ |
Max working pressure(bar) | 18 | 18 | 18 | 18 | 18 | 18 | 18 |
Test Pressure(bar) | 29 | 29 | 29 | 29 | 29 | 29 | 29 |
Min Wall-thickness(mm) | 0.8 | 1.07 | 1.2 | 1.2 | 1.25 | 1.3 | 1.32 |
Material | SPCC | SPCC | SPCC | SPCC | SPCC | SPCC | SPCC |
Fire Rate | 8A 21B | 13A 34B | 13A55B | 13A70B | 21A113B | 34A183B | 43A 233B |
Packing Size(MM) | 45X20.5X36/6pcs | 36X25X42/4pcs | 14.5X14X45 | 15X15X54 | 17.5X17X55.5 | 19.5X19X62 | 20X20X66 |
Standard | BS EN3-8 | BS EN3-8 | BS EN3-8 | BS EN3-8 | BS EN3-8 | BS EN3-8 | BS EN3-8 |
